Automatic knife grinding machine
Feature:
1. Knife grinder is automatic to grind knife.
2. Worktable is electromagnetic chuck. Put knife on the worktable, the knife will be fixed on it.
3. It can adjust the angle of worktable from 0°-90°.
Parameter:
|
Model
|
YM1500B
|
YM3000B
|
YM3500B
|
YM4500B
|
|
Max. grinding length
|
1500mm
|
3000mm
|
3500mm
|
4500mm
|
|
Worktable width
|
180mm
|
180mm
|
200mm
|
200mm
|
|
Motor of grinding head
|
4kw
|
4kw
|
4kw
|
4kw
|
|
Linear speed of wheel
|
15m/s
|
15m/s
|
15m/s
|
15m/s
|
|
Grinding head move speed
|
15.2m/min
|
12/18m/min
|
12/18m/min
|
12/18m/min
|
|
Angle range of worktable
|
90°
|
90°°
|
90°
|
90°
|
|
Overall size
|
322x125x130mm
|
490x125x130mm
|
550x125x130mm
|
650x125x130mm
|
|
Weight
|
1500kg
|
2900kg
|
3200kg
|
3800kg
|
